Protect your Raspberry Pi-based industrial projects from power outages and data loss with UPSafePI, the innovative Industrial UPS that delivers uninterrupted power supply and reliability.
Designed to perform in challenging environments, UPSafePI is the ultimate solution to safeguard your critical operations, reduce downtime, and secure your hardware investment.
Key features
Robust power protection
Shield your Raspberry Pi from power problems and data loss with surge protection and voltage regulation.
Seamless Power Continuity
Keep your Raspberry Pi running during outages with battery backup. Switch back to AC power when available.
Extended Battery Life
Enjoy long-lasting power backup with a high-capacity, rechargeable battery. Get alerts for battery replacement.
Versatile Connectivity Options
Connect your Raspberry Pi to various industrial applications with USB, Ethernet, and GPIO ports.
Optional Raspberry Pi Bundle
Get the latest Raspberry Pi model with UPSafePI for a complete solution without sourcing components separately.
Easy Installation and Setup
Install and customize UPSafePI easily with clear instructions and software tools.
Model Type | UPS & RTC Shield |
Input Voltage | 12 to 24Vdc (Fuse protection (3A) Polarity protection) |
Input rated voltage | 24Vdc |
Rated POwer | 30 W |
I max. | 3.5A |
Compatibility | All Raspberry Pi 2, 3, 4 & All Raspberry Pi B models |
Communications & Accessories | RS-485, ICSP connector, I2C (3.3V), USB Type-C (Power Only), |
Power supply voltage | Screw terminal: 12 to 24Vdc |
USB terminal: 5Vdc | |
Power consumption | DC power supply: 20 W MIN. |
Average input current | 0.5A |
Insulation resistance | 20mΩ https://min.at/ 500Vdc between the AC terminals and the protective earth terminal. |
Dielectric strenght | 2.300 VAC at 50/60 Hz for one minute with a leakage current of 10mA max. |
Ambient temperature (operating) | 0º to 60º C |
Ambient humidity (operating) | 10% to 90% (no condensation) |
Ambient environment (operating) | With no corrosive gas |
Ambient temperature (storage) | -20º to 60ºC |
Raspberry Board | Raspberry Pi 4 B |
I/O control method | Combination of the cyclic scan and immediate refresh processing methods. |
Programming language | Linux applications: Bash Scripts, Python, C++, Node-Red and more!. |
CPU | Broadcom BCM2711, Quad core Cortex-A72 (ARM v8) 64-bit SoC @ 1.5GHz |
Website | https://www.raspberrypi.org/ |
